I came in to comment about wheel bearings, but this last page has thrown me off, somewhat.

Anyway... yeah, my BMW has just been loaded on to a truck because of a wheel bearing too. BMW don't class that as a mechanical failure, so I don't have any sort of replacement vehicle. That's fine, I'll just work from home indefinitely because all workshops are booked up until the end of June.

Shitty customer service.

Link to comment
Share on other sites

I've had noisy bearings with no play in the past too. Usually if you hold the suspension spring and spin the wheel you can feel the roughness in the bearing amplified by the springs wobblyness when you can't feel it otherwise. Could be worth a go before messing around with gearboxes.

I've had rears sound like fronts and left's sound like rights etc too, so check all 4 before ruling them out.

Link to comment
Share on other sites

Ah Mike, that's a PITA to say the least. Hopefully they take the nudge and step it up a notch for you.

@Ads, cracking post on WSCC earlier. Hope things are good with you at the mo, had meant to ping you an email after a recent update but must have got sidetracked.


I've not really updated much here for my own car lately. Bit of copypasta from another forum so excuse the fact this clearly won't flow but long story short, daily duties, MOT, blah blah blah, stripped old engine, building up a stroker to replace, fitted a standalone ECU last week (I am the weak link in this package).

In fact, feck it, here's a largely photographic catchup instead.
























The old inlet mani gasket was still in place on the head. Can see here how the casting is slightly wonky relative to the machining. This could potentially be sorted with some grinding to gasket-match things.


Here’s the worst one. Significantly better at the other end.


Oh, and since I had them both to hand, here’s a quick look at the significant difference between small and large port heads.




Going for a bit of a roadtrip this the weekend.


Productive weekend on the most part. Didn't start so well, getting home to find Boost with is ear in bits. He'd been attacked by an bum hole Bengal cat over the road and wasn't in a great way, with his ear only held together by fur and his ear canal full of blood. Emergency surgery later and my wallet was well and truly hurting before we'd even set off. Not so much as his pride having to wear a Cone of Shame mind...


Zipped up the M5, dropped off the old LCR Brembos mentioned before to the home of a certain Badger. Picked up a few goodies and left.


Firstly these are what I'd swapped the brakes for. CatCams (3668s IIRC) and it's pretty apparent that there's significantly more lift and longer duration, plus these are designed to be VVT safe which will be very handy. Here they are next to a set from an AMK lump, though most are similar/the same. Not sure I'll be needing these for a considerable amount of time, if ever, but at only 400 miles old these seemed a decent upgrade to have handy rather than some scabby old brakes I'll never need.


To go with those, one of these.


And lastly, a new toy to play about with.


Very impressed by the new housings - machined from billet, these look baller (not that you'll see it often) but mainly act as a heatsink for the black magic that lies within. Happy days! Very much looking forward to playing with this and learning more along the way.


Both cars were due MOTs last week. New ticket sorted on each of them with no fuss. Did have to knock up a cat section by welding the two stock twin LCR cats in series to get it through, but emissions read super low so clearly did the trick. It’s also cost me at least 5bhp by sticking a massive restriction in the exhaust if logs are anything to go by, so whether or not it'll stay is anyone's guess...  :lol




Sold my old rods. I say old, they’d been used for under 150 miles in the old engine before the head slightly intoxicated me off enough to rip it all out. Sold for more than I paid, so can’t complain really.


Went up to London as Soph’s cousin was running the marathon. Mostly boring, but detoured to Bath on the way home and picked up the stuff I’d dropped off a fortnight prior. Here’s one of those bits receiving a little paint. Block has been acid and caustic dipped to clean off old paint, gunk, grease and rust. Has then been rebored to 82.5mm, honed, and decked to ensure a perfect face for sealing up.



Popped off the intake mani to rework stuff. I’ve simplified the PCV setup a little as there’s no real need for the full extent of split-happy pipework the factory fitted IMO. Now just a single line from the T-piece up to the nipple on top of the TB (used for EVAP as stock, IIRC). With this moved, there’s an 8mm nipple on the base of the mani which I can use for the MAP sensor, which needs to be fitted to the manifold rather than in the pipework before the TB as I’ll be ditching the MAF and running a Speed Density tuning method in the future.



Made a new friend while I was working. Someone in our road appears to have a new, extremely cute, kitten. Lovely little thing, until it started chewing on my DV line…


After 4 days of our entire family being horrifically ill, I needed some fresh air. Wasn’t really up to driving or going anywhere, so the drive was the perfect location for a couple of hours in the sun playing with the standalone setup.

Plugged in the new ECU to both the car and laptop, turned the key to give power and instantaneously received notice that all drivers had been installed. Always a good start.

I configured the throttle pedal minimum and maximum positions, then performed basic settings on the throttle itself. Being a DBW car (Ignitron is an ME7.5 replacement) this is essential, though a number of people seem have missed these steps and had issues down the line. No wonder, really. Followed this up with a general fault code scan and nothing to report at this stage. Bonus. Checked the gauges and all appeared sensible, so time to turn the key.

The car fired up and other than running rich everything seemed to be pretty reasonable. Impressive stuff from the base file wizard built into the software really, as I certainly don’t know enough at this stage to have made it this far alone

At this point, unwell child woke up so car was shut off, stock ECU quickly connected back up, and the car abandoned for a while. As I’d need it in the morning and didn’t have time to play with getting things running right, it seemed sensible to have another proper go next weekend when time allowed.

With wife and child both still feeling rough and going to bed about 8ish, I pinched another hour and went back outside to refit the scuttle and wipers so I could actually use the car properly for the week. Moments later, my willpower cracked and I ended up removing the stock ECU permanently in lieu of the new unit instead :lol:





I ran a serial-USB line through the same bulkhead panel and the main wiring harness, so it drops down behind the dash with the main fuse panel and pops out of the cubby hole by the driver’s right knee. Waiting on some rubber grommets to tidy up the holes a little, as I had to chain drill and file due to losing my chuck key and being too impatient…




Anyway, with the car back together I went inside to watch the latest episode of Project Binky before bed. Made a few tweaks to my map whilst watching - mainly VE table, warmup lambda table and a couple of minor adaption elements. Flashed this onto the car before work this morning and seems to be helping, but will check logs tonight/tomorrow and see where we are.

Steep learning curve begins here!

Had a little time this afternoon so dug out piston rings and got them gapped. I’ll give them another check prior to fitting but very happy with how consistent these are. Tops were extremely hard which is reassuring, but meant they were an absolute pig to file down and took considerable time, but worth doing right of course. Second rings were noticeably softer, wearing down much faster.



Took it super slow with lots of checking and they are all pretty much bang on where I want them at 0.5mm top, 0.525 second rings.


All now look something like this. As is standard practice, you should only ever file one side of the gap, giving a reference side to work from ensuring the two ends are as close to parallel as possible.


Had time before heading out to check out the new oil squirters I picked up - these are TFSI units and the body is a slightly different profile to 1.8t variants. Shouldn’t really have an issue with either, but I liked the idea of the additional clearance, particularly since I’m running a stroker crank.


Pistons are profiled to suit, as seen here


Gave the crank a quick glance this weekend too. I've still got to change the trigger wheel over for a new one, as both bolts and the wheel itself are single use which not many people seem to be aware of. Given I don't know the full history of this crank out seems foolish not to, and the parts were dirt cheap from the dealer anyway so it's a no brained. For now, however, just swapped over the oil pump drive gear. Again, cheap from the dealer and you can see the difference below.



These are an interference fit, so with a bit of heat the old gear popped off no problem. In order to get the new one on, it went into the oven to warm up for a bit then pressed on.


Handy tip for any trials riders out there - Pro II freehub seal tool is the perfect size for this. For anyone else, a bit of 40mm pipe will do just fine.


Regarding the ECU/tuning, I’m slowly getting to grips with it all. I feel like I’ve learnt a huge amount in the past week alone, though still a million miles to go yet. Only real niggle so far was having a bit of a moment in the week - there was an audible pop followed by a drop in power and reluctance to idle below 1000rpm. Serves me right for forgetting to put a clip on the MAP hose really, and the 8mpg I got for the rest of that drive home were entirely deserved as a result haha.

I’ve got the VE table to a place I’m pretty happy with, though I’m well aware this is unlikely to ever be “done” as such so will continue to let it learn through use. I’ve turned down the ratios a little, so that if I do choose to apply the generated adaption tables then they have a lesser impact moving forward now that the bulk crude chunk has been done.


I’ve also rerouted my ECU connection slightly, which has tidied it away inside the scuttle so it’s a little further from the wiper linkage. Wasn’t strictly necessary, but for peace of mind nice to have done. It did, however, mean that I barely had enough cable left to reach the laptop inside the car. Easy solution.


  • Like 1
Link to comment
Share on other sites

Cheers Luke!

Looks like you ave been a busy boy as well. Top stuff and a good read.

The map you've posted above - I've always down the route of keeping the tables smooth, and that's what my mapper has said too. Example is that cell at 2500rpm / 140 kpa, it's higher than the two columns next to it so the engine - which is effectively a big inertia lump - is trying to slow down then speed up then slow down as it goes through that part of the map. Same sort of thing with the 'dip' at 2250 / 80.

Your 5000rpm column is buttery smooth for example, with even and consistent differences between the values. If you can get them all like that while still maintaining a consistent difference in values to the left and the right (lower and higher rpm columns) it should run even better. Hope that makes sense?

Link to comment
Share on other sites

Good spot, thanks Adam - that's actually a screenshot from the previous iteration of the map post-adaptions but before manual smoothing which I always follow up with. 2D mode is very handy for that, taking one row or column at a time and making the transitions a little nicer :)

There are also some regions of the map I've simply not touched (because frankly driving around on the public roads trying to hit each cell, 300kPa and 8000rpm etc, just isn't going to happen. We can't all be running bike engines you know...) Those regions are populated through a combination of a base file and a few similar engines, so are likely a little out from reality but should be in the right ballpark.

Given I'll be changing displacement soon(ish) I won't really be pushing the limits here as it doesn't seem worthwhile. Rather, I'll be taking it slowly and trying to refine things and learn at stock-ish power levels. For example, while I understand the basics of VE, I'm not too sure how to best go about tuning timing yet so playing it very safe. As much as I can understand the method of pushing it a little until it knocks, then pegging it back a touch, there must surely be a more scientific way to go about things?! :lol:

  • Like 1
Link to comment
Share on other sites

Haha. Been following DannyDC2, Dann? :lol: Do like a good MR2!

to be honest Luke that is about all there is to it - a good dyno tuner will install a knock sensor, keep bumping the timing until it knocks, or stops making power, then pull it back a couple of degrees. Do that for all the RPM and TPS sites and hey presto, a beautiful map that is both economical and makes the best power possible (narks me when people say they have got a map 'for power' or 'for economy' - they aren't mutually exclusive!).

You're in for a really rewarding and fun learning process, keen to see how it turns out!



Video from first competitive outing on Saturday... missed out on fastest car on road (1B MSA list) tyres by 0.04s to this: https://www.fensport.co.uk/fensport-cars/gt86r-turbo/

Gutted at the time, but with reflection I can't complain.

And a comparison with one of the 'big boys' (winner of the last round of this sprint series) - shows how much quicker a heavier car with 4WD heats tyres! He must be nearly 3s ahead after the first lap, but I finish nearly 2s ahead.

http://www.youtubemultiplier.com/5ce197c58fad5-big-power-vs-low-weight.php

Link to comment
Share on other sites

I can see how that little a gap would be a bit of a mind melter - when it's something as insignificant as that that could have been caused by/avoided by doing the tiniest of things differently it seems like it would be worse than being quite a bit off due to one major thing in a way.  Still though, to be that close to a well established, lengthy-development car like that when you're just starting your own path is encouraging (Y)

I bet that car won't have been half as fun either - screaming up through the gears onto the back not-quite-straight and seeing it slithering round: yes please.

Link to comment
Share on other sites

Cheers dude! Lots of little tiny reasons as you said - one being putting 5L too much fuel in which would account for that 0.2s on my final run... Never mind, what's done is done!

Yeah, the GT86 doesn't look half as much fun on the in-car, it sure has some bant though B)



Link to comment
Share on other sites

10 hours ago, Adam@TartyBikes said:

Haha. Been following DannyDC2, Dann? :lol: Do like a good MR2!

to be honest Luke that is about all there is to it - a good dyno tuner will install a knock sensor, keep bumping the timing until it knocks, or stops making power, then pull it back a couple of degrees. Do that for all the RPM and TPS sites and hey presto, a beautiful map that is both economical and makes the best power possible (narks me when people say they have got a map 'for power' or 'for economy' - they aren't mutually exclusive!).

You're in for a really rewarding and fun learning process, keen to see how it turns out!



Video from first competitive outing on Saturday... missed out on fastest car on road (1B MSA list) tyres by 0.04s to this: https://www.fensport.co.uk/fensport-cars/gt86r-turbo/

Gutted at the time, but with reflection I can't complain.

And a comparison with one of the 'big boys' (winner of the last round of this sprint series) - shows how much quicker a heavier car with 4WD heats tyres! He must be nearly 3s ahead after the first lap, but I finish nearly 2s ahead.

http://www.youtubemultiplier.com/5ce197c58fad5-big-power-vs-low-weight.php

Haha you could say that.



Keep an eye out from an order from me soon, got a new bike tonight :D

Link to comment
Share on other sites

Is Danny dc2 the nurburgring slayer in that k20 mr2? His mate executes that's stunning fwd drift in that dc5 :wub:

Got someone local on the hook to buy the fairlane, kinda dont want it to stay around as I dont want to see it driving around but a sales a sale. The idea was to put the money into my business and give cars a break for a while, then get back into it when I can afford something dream status, but my juke picker in the states has spotted a 61 Caddilac coupe deville bubbletop that's given me mild feels...

  • Like 1
Link to comment
Share on other sites

Collected my EG6 last night. Paint needs attention but the shell is solid.



K20 is out of the coupe for head gasket doing, final drive, 4th 5th and 6th year replacement and diff rebuild.


Del Sol VTI arriving next month that I’m planning on robbing the B16 from to go in the blue EK shell I aquired with the unit.


Business insurance in place for my unit. B16 swapped EK in for an engine rebuild over the next few weeks, EF Civic B swap is building up component wise and a few K series boxes to do. All go!



  • Like 4
Link to comment
Share on other sites

Looks like you're keeping busy Sam! Is that you off track days for a bit now or should we try and get another TF day sorted out? :D

I was at Cadwell on Thursday. Busy on track all day and a few car niggles, no clear laps but it was generally a fun day and has given me more stuff to tinker with!





Link to comment
